8CH USB Logic Analyzer
8CH USB Logic Analyzer
The 8CH USB Logic Analyzer is a powerful and versatile tool designed for debugging, testing, and analyzing digital circuits and microcontrollers. This device captures and displays the logical signals of up to 8 channels simultaneously, providing a comprehensive understanding of digital signal behavior. The analyzer connects to a computer via a USB interface, making it easy to use and integrate into various development environments.
| The 8CH USB Logic Analyzer is used to |
Capture and display digital signal waveforms of up to 8 channels
Analyze and decode digital protocols such as SPI, I2C, UART, and more
Measure signal frequency, pulse width, and duration
Trigger on specific events or patterns in the signal
Log and save signal data for later analysis
Interface with various development software and tools
8
Up to 100MSa/s
0-5V
100k
Edge, pulse, and pattern
USB 2.0
Windows, macOS, and Linux compatible
60mm x 40mm x 20mm
50g
| The 8CH USB Logic Analyzer is suitable for a wide range of applications, including |
Digital circuit design and debugging
Microcontroller development and testing
Embedded system development and integration
IoT development and prototyping
Digital signal processing and analysis
The 8CH USB Logic Analyzer is a powerful and versatile tool that provides a comprehensive understanding of digital signal behavior. With its high-speed sampling, protocol analysis, and compact design, it is an essential tool for anyone working with digital circuits and microcontrollers.
8CH USB Logic Analyzer DocumentationOverviewThe 8CH USB Logic Analyzer is a powerful tool for debugging and analyzing digital signals in various electronic systems. It provides 8 channels of logic analysis, allowing users to capture and analyze signals from multiple sources simultaneously. This documentation provides an overview of the component's features, specifications, and code examples to help users integrate it into their projects.Features and Specifications8 channels of logic analysis
Maximum sampling rate: 24MHz
Input voltage range: 0V to 5V
USB 2.0 interface for connection to PC
Compatible with Windows, macOS, and Linux operating systems
Includes software for capturing, analyzing, and exporting dataCode Examples### Example 1: Using the 8CH USB Logic Analyzer with Python for Signal CaptureIn this example, we will use the `pyusb` library in Python to communicate with the 8CH USB Logic Analyzer and capture a signal on all channels.Python Code
```python
import usb.core
import usb.util# Find the device
dev = usb.core.find(idVendor=0x03eb, idProduct=0x6124)# Set the configuration
dev.set_configuration()# Claim the interface
cfg = dev.get_active_configuration()
intf = cfg[(0,0)]# Set the sampling rate and trigger mode
intf.write(0x01, b'x01x00x00x00') # 24MHz sampling rate, trigger mode = 0# Capture data on all channels
data = intf.read(0x81, 1024, 1000) # Read 1024 bytes of data from all channels# Print the captured data
for i in range(8):
channel_data = data[i128:(i+1)128]
print(f"Channel {i}: {', '.join([f'0x{x:02x}' for x in channel_data])}")
```
This code example assumes that the 8CH USB Logic Analyzer is connected to the PC and configured for 24MHz sampling rate and trigger mode 0. The code captures 1024 bytes of data from all channels and prints the data in hexadecimal format.### Example 2: Using the 8CH USB Logic Analyzer with C++ for Triggered CaptureIn this example, we will use the `libusb` library in C++ to communicate with the 8CH USB Logic Analyzer and capture a signal on all channels using a triggered capture mode.C++ Code
```c
#include <libusb.h>
#include <iostream>int main() {
libusb_context ctx = libusb_init(NULL);
libusb_device_handle devh = libusb_open(0x03eb, 0x6124, NULL);// Set the configuration
libusb_claim_interface(devh, 0);// Set the sampling rate and trigger mode
unsigned char cmd[] = { 0x01, 0x00, 0x00, 0x00 }; // 24MHz sampling rate, trigger mode = 1
libusb_control_transfer(devh, 0x21, 0x09, 0x01, 0x00, cmd, 4, 1000);// Set the trigger condition (e.g., rising edge on channel 0)
unsigned char trig[] = { 0x02, 0x00, 0x00, 0x00, 0x01, 0x00, 0x00, 0x00 };
libusb_control_transfer(devh, 0x21, 0x09, 0x01, 0x01, trig, 8, 1000);// Capture data on all channels
unsigned char data[1024];
libusb_bulk_transfer(devh, 0x81, data, 1024, &transferred, 1000);// Print the captured data
for (int i = 0; i < 8; i++) {
std::cout << "Channel " << i << ": ";
for (int j = 0; j < 128; j++) {
std::cout << std::hex << (int)data[i128 + j] << " ";
}
std::cout << std::endl;
}libusb_release_interface(devh, 0);
libusb_close(devh);
libusb_exit(ctx);
return 0;
}
```
This code example assumes that the 8CH USB Logic Analyzer is connected to the PC and configured for 24MHz sampling rate and trigger mode 1 (triggered capture). The code sets the trigger condition to capture data on all channels when a rising edge is detected on channel 0. The captured data is then printed to the console in hexadecimal format.Note: The code examples provided are for illustration purposes only and may require modification to suit specific use cases and project requirements.
