LM12UU 12mm Linear Motion Bearing for 3D Printer

Buy Now on Stufin

Component Name

Overview

The LM12UU 12mm Linear Motion Bearing is a type of linear motion system component designed specifically for 3D printing applications. It is a critical component in 3D printer designs, enabling smooth and precise linear movement of the print head, X-axis, or Y-axis. This bearing provides low friction, high accuracy, and reliability, making it an essential element in achieving high-quality prints.

Functionality

The primary function of the LM12UU 12mm Linear Motion Bearing is to facilitate linear motion in 3D printing systems. It allows the print head or axis to move smoothly and precisely along a straight path, ensuring accurate deposition of material and high-quality prints. The bearing achieves this by minimizing friction and providing a stable, consistent motion profile.

Key Features

Bore Diameter: The LM12UU has a bore diameter of 12mm, making it compatible with standard 3D printer shafts and axes.
Linear Motion: The bearing is designed for linear motion, providing smooth and precise movement along a straight path.
Low Friction: The bearing features a low-friction design, minimizing resistance and ensuring smooth motion.
High Accuracy: The LM12UU bearing provides high accuracy and repeatability, making it suitable for demanding 3D printing applications.
Reliability: The bearing is designed to withstand the rigors of continuous use, providing a reliable and consistent performance.
Compact Design: The LM12UU has a compact design, making it ideal for space-constrained 3D printer designs.
Easy Installation: The bearing is easy to install and integrate into 3D printer designs, simplifying the assembly process.
Durable Construction: The LM12UU is built with durable materials, ensuring a long service life and minimizing the need for maintenance or replacement.
Compatibility: The bearing is compatible with a wide range of 3D printer designs and configurations, making it a versatile component for various applications.

Specifications

Bore diameter

12mm

Outer diameter

21mm

Length

43mm

Material

Steel or Stainless Steel

Dynamic load rating

450N

Static load rating

900N

Operating temperature range

-20C to 120C

Applications

The LM12UU 12mm Linear Motion Bearing is commonly used in 3D printer designs, including

Cartesian 3D printers

Core XY 3D printers

Delta 3D printers

CNC machines

Robotics and automation systems

Conclusion

The LM12UU 12mm Linear Motion Bearing is a high-performance component designed specifically for 3D printing applications. Its low friction, high accuracy, and reliability make it an essential element in achieving high-quality prints. With its compact design, easy installation, and compatibility with various 3D printer designs, the LM12UU is a popular choice among 3D printing enthusiasts and professionals alike.
