3M USB to Micro USB Cable Black Documentation

Component Name

3M USB to Micro USB Cable Black

Overview

The 3M USB to Micro USB Cable Black is a high-quality, durable cable designed for connecting devices with a standard USB port to devices with a micro-USB port. This cable provides a reliable and efficient way to transfer data and power between devices, making it an essential accessory for a wide range of applications.

Functionality

Data Transfer: The cable enables the transfer of data between devices, allowing users to transfer files, images, and videos.
Power Delivery: The cable can deliver power from a USB power source to a micro-USB device, enabling charging and powering of devices.
Hot Swapping: The cable supports hot swapping, allowing users to connect and disconnect devices without shutting down the system.

The primary function of the 3M USB to Micro USB Cable Black is to establish a connection between a USB-enabled device (such as a computer or wall adapter) and a micro-USB enabled device (such as a smartphone, tablet, or camera). This allows for

Key Features

Length: The cable measures 3 meters (10 feet) in length, providing a convenient distance for connecting devices.
USB Type-A Connector: The cable features a standard USB Type-A connector on one end, compatible with most computers and wall adapters.
Micro-USB Connector: The cable features a micro-USB connector on the other end, compatible with most smartphones, tablets, and cameras.
Black Color: The cable has a sleek black color, making it easy to distinguish and organize.
Durable Construction: The cable is built with high-quality materials and construction, ensuring a long lifespan and resistance to damage.
Flexible Cable: The cable is flexible and easy to bend, making it easy to use in confined spaces or for traveling.
Fast Data Transfer: The cable supports fast data transfer speeds, ensuring efficient transfer of files and data.
Safety Certification: The cable meets safety certifications, ensuring safe and reliable operation.

Cable length

3 meters (10 feet)

USB Type-A connector	Standard USB Type-A
Micro-USB connector	Standard micro-USB

Color

Black

Material

Durable, flexible material

Data Transfer Speed

Up to 480 Mbps

Power Delivery

Up to 2.5A

Operating Temperature

0C to 40C (32F to 104F)

Storage Temperature

-20C to 60C (-4F to 140F)

Applications

The 3M USB to Micro USB Cable Black is suitable for a wide range of applications, including

Charging and powering smartphones, tablets, and cameras

Transferring data between devices

Connecting devices to computers or wall adapters

Travel and on-the-go use

Home and office use

Warranty and Support

The 3M USB to Micro USB Cable Black comes with a manufacturer's warranty and dedicated customer support, ensuring a hassle-free experience and quick resolution of any issues.

Pin Configuration

Component Documentation: 3M USB to Micro USB Cable Black
Introduction
The 3M USB to Micro USB Cable Black is a standard cable used for connecting devices with a Micro-USB port to a host device with a USB port, such as a computer or wall adapter. This cable is commonly used for charging and data transfer between devices.
Pinout Structure
The USB to Micro USB Cable consists of two connectors: a Standard-A USB connector and a Micro-B USB connector. The pinout structure for each connector is as follows:
Standard-A USB Connector (Host Side)
Pin 1: VCC (Voltage Supply)
+ Function: Provides power to the device
+ Voltage: +5V
Pin 2: D- (Data -)
+ Function: Carries data signals from the host device to the device
Pin 3: D+ (Data +)
+ Function: Carries data signals from the host device to the device
Pin 4: GND (Ground)
+ Function: Provides a ground connection for the device
Pin 5: Shield
+ Function: Provides shielding for the cable to reduce electromagnetic interference (EMI)
Micro-B USB Connector (Device Side)
Pin 1: VCC (Voltage Supply)
+ Function: Receives power from the host device
+ Voltage: +5V
Pin 2: D- (Data -)
+ Function: Receives data signals from the host device
Pin 3: D+ (Data +)
+ Function: Receives data signals from the host device
Pin 4: ID (Identification)
+ Function: Used for device identification and configuration
Pin 5: GND (Ground)
+ Function: Provides a ground connection for the device
Pin 6: Shell
+ Function: Provides shielding for the cable to reduce electromagnetic interference (EMI)
Connection Structure
To connect the pins properly, follow these steps:
1. VCC (Pin 1): Connect the VCC pin on the Standard-A USB connector to the VCC pin on the Micro-B USB connector. This ensures power is supplied from the host device to the device.
2. D- (Pin 2): Connect the D- pin on the Standard-A USB connector to the D- pin on the Micro-B USB connector. This allows data to be transmitted from the host device to the device.
3. D+ (Pin 3): Connect the D+ pin on the Standard-A USB connector to the D+ pin on the Micro-B USB connector. This allows data to be transmitted from the host device to the device.
4. GND (Pin 4): Connect the GND pin on the Standard-A USB connector to the GND pin on the Micro-B USB connector. This provides a common ground connection between the devices.
5. Shield (Pin 5): Connect the Shield pin on the Standard-A USB connector to the Shell pin on the Micro-B USB connector. This ensures proper shielding and reduces electromagnetic interference.
Note: Make sure to handle the cable with care to avoid damaging the pins or the insulation. Always connect the cable to the correct ports on the host device and the device to avoid damage or malfunction.
By following this documentation, you should be able to properly connect the 3M USB to Micro USB Cable Black and ensure reliable data transfer and power supply between devices.

Code Examples

Component Documentation: 3M USB to Micro USB Cable Black

Overview

The 3M USB to Micro USB Cable Black is a high-quality, 3-meter cable designed for connecting devices with a micro-USB port to a computer or wall adapter with a standard USB port. This cable is ideal for charging and data transfer applications, making it a versatile and reliable component for various IoT projects.

Technical Specifications

Cable length: 3 meters
 Connector type: USB (Type-A) to Micro-USB (Type-B)
 Compatibility: Devices with micro-USB ports, such as Android smartphones, tablets, and IoT modules
 Data transfer rate: Up to 480 Mbps
 Power rating: Up to 2.5A

Code Examples

The following code examples demonstrate how to use the 3M USB to Micro USB Cable Black in various contexts:

Example 1: Raspberry Pi with Python

In this example, we will use the cable to connect a Raspberry Pi to a computer for programming and debugging. We will create a simple Python script to blink an LED connected to the Raspberry Pi's GPIO pins.

Hardware Requirements

Raspberry Pi (any model)
 LED
 Breadboard
 Jumper wires
 3M USB to Micro USB Cable Black

Software Requirements

Python 3.x
 Raspbian OS (or similar)

Code
```python
import RPi.GPIO as GPIO
import time

# Set up GPIO mode
GPIO.setmode(GPIO.BCM)

# Define the LED pin
LED_PIN = 17

# Set up the LED pin as an output
GPIO.setup(LED_PIN, GPIO.OUT)

try:
    while True:
        # Blink the LED
        GPIO.output(LED_PIN, GPIO.HIGH)
        time.sleep(1)
        GPIO.output(LED_PIN, GPIO.LOW)
        time.sleep(1)

except KeyboardInterrupt:
    # Clean up GPIO on exit
    GPIO.cleanup()
```
Example 2: Arduino with Serial Communication

In this example, we will use the cable to connect an Arduino board to a computer for serial communication and debugging. We will create a simple Arduino sketch to send a "Hello, World!" message to the serial console.

Hardware Requirements

Arduino Board (any model)
 3M USB to Micro USB Cable Black
 Computer with Arduino IDE installed

Software Requirements

Arduino IDE (any version)

Code
```c
void setup() {
  Serial.begin(9600); // Initialize serial communication at 9600 baud
}

void loop() {
  Serial.println("Hello, World!"); // Send a message to the serial console
  delay(1000); // Wait 1 second before sending the next message
}
```
These code examples demonstrate the versatility and reliability of the 3M USB to Micro USB Cable Black in various IoT applications. Whether you're working with Raspberry Pi, Arduino, or other microcontrollers, this cable is a valuable component for any project.
