Description: 1. Features: TB6560 is a microstepping driver that supports stepper motors with up to 3A continuous current per phase. It comes with 4 independent channels, allowing simultaneous operation of two motors or driving multiple steps on a single motor. 2. Microstepping: With its precise microstepping capability (1/16th, 1/8th, and 1/32th steps), the TB6560 offers smooth motion control, making it suitable for applications requiring high-resolution positioning or fine motor control. 3. Acceleration: The driver supports acceleration and deceleration, enabling precise speed control at start and stop to prevent shock loads on the motor or damage to gears. 4. Flexible Configuration: The TB6560 offers various configuration options through external DIP switches for setting step pulse polarity, motor direction, acceleration/deceleration rates, and microstepping resolution. 5. Protection Circuitry: This driver features over-current, overheat, and short circuit protection to ensure safe operation
| Specification | Details |
|---|---|
| Driver Type | Bipolar 4-phase stepper motor driver |
| Voltage Rating | 24V DC (operating voltage) |
| Current Rating | Up to 2A per phase (per output) |
| Step/Direction Pins | Single 3.3-5V logic compatible |
| Microstep Resolution | Microsteps: 1/16 1/32 1/64 |
| Max Speed | 40000 steps/sec |
| Power Dissipation | Up to 15W (depending on load) |
| Operating Temp. | -10°C to 85°C |
| Weight | Approximately 35g |
| Dimensions | 42mm x 40mm x 16mm |
| Mounting Type | Through-hole (THT) connections |
| Compatibility | Compatible with most stepper motors |
