Description: 1. Features: The 16-channel analog multiplexer is an electronic component with 16 input channels and one output channel. It allows selective routing of analog signals from any of the input channels to the single output channel. 2. Applications: This multiplexer finds extensive use in various IoT projects involving data acquisition, signal conditioning, and system expansion. It enables interfacing multiple sensors or analog sources with a limited number of input channels on data acquisition devices or microcontrollers. 3. Mux Control: The component comes with an integrated control unit that allows users to select the desired input channel through digital addresses (Address Select Register – ASR) or by applying specific voltages at the control pins. 4. Flexible Interfacing: The 16-channel analog multiplexer enables flexible interfacing of different sensors or sources with minimal modifications to the system design, making it an essential part of modular and expandable IoT setups. 5.
| Specification | Details |
|---|---|
| Number of Channels | 16 |
| Channel Selection | Software-controlled via SPI/I2C interface |
| Resolution | Up to 18 bits (depending on the input) |
| Input Range | ±10V (can be adjusted via software) |
| Output Impedance | High impedance (>100 kΩ) |
| Operating Voltage | +5V ±12V or ±15V |
| Operating Temperature | -40°C to +85°C |
| Supply Current | ≤10 mA (depending on the input and voltage) |
| Package Type | DIP-16 or SOIC-20 |
| Interface | SPI I2C or TTL |
| Switching Speed | Up to 1 MHz (depending on the application) |
