Description: 1. Bluetooth Version: DX-BT18 is a dual-mode Bluetooth module that supports both SPP2.0 (Serial Port Profile) and BLE4.0 (Bluetooth Low Energy). 2. Data Transfer Protocols: It offers two data transfer protocols: SPP for robust, stable, and continuous data transmission and BLE for power-efficient, low-data rate applications. 3. Operating Range: The module boasts an impressive operating range of up to 10 meters (line of sight) for classic Bluetooth connections and up to 50 meters for BLE connections. 4. Transparent Serial Port: DX-BT18 functions as a transparent serial port, allowing the direct transmission of data between two devices without any modification or interpretation from the module itself. 5. Versatile Applications: This Bluetooth module can be used in a variety of applications such as remote control systems, IoT projects, health monitoring systems, and more due to its dual-mode capability and transparent serial port feature. 6. Power Consumption: For BLE applications, D
| Specification | Details |
|---|---|
| Bluetooth Version | SPP 2.0 + BLE 4.0 |
| Module Type | Bluetooth Dual-Mode Module |
| Interface | Transparent Serial Port (TX RX) |
| Operating Frequency | 2.4 GHz |
| Data Rate | Up to 3 Mbps |
| Range | Up to 100 meters |
| Power Consumption | 20 mA (Typical) 30 mA (Max) |
| Operating Voltage | 3.0V to 4.2V |
| Current Rating | -40°C to 85°C |
| Dimension | 14mm x 10mm x 2.5mm |
| Weight | Approximately 1g |
| Certifications | CE RoHS FCC etc. (Depends on Region) |
| Mounting Options | SMT (Surface Mount Technology) |
