LM2596 DC-DC Step-down Buck Module with Display

Stufin

LM2596 DC-DC Step-down Buck Module with Display

This product is not available in your location yet

Description: 1. LM2596 is a versatile DC-DC step-down (buck) module capable of converting higher input voltage levels into lower output voltages with adjustable precision. This specific version features an integrated display for real-time voltage monitoring. 2. Input Voltage Range: The LM2596 buck module accepts input voltages between 7V to 35V, making it suitable for various power sources like batteries or solar panels. 3. Output Voltage Adjustment: Users can easily set the desired output voltage by adjusting a single potentiometer (pot) on the board. The output voltage ranges from 1.2V to 18V, depending on the input voltage level. 4. Integrated Overvoltage Protection: This module comes with built-in protection against overvoltage conditions, ensuring optimal performance and longevity of the connected components. 5. Efficiency: The LM2596 DC-DC converter boasts an impressive efficiency rate of up to 80%, minimizing energy loss during power conversion. 6. Compact Design: Despite its robust fe

View Technical Documentation

Specification	Details
Input Voltage Range	3V to 35V (for output voltage)
Output Voltage	Adjustable from 1.25V to 37V in 100mV steps
Output Current	Up to 3A (dependent on heat sink and input voltage)
Efficiency	Up to 95%
Switching Frequency	Fixed at 150kHz
Display	1.8" LCD display with adjustable backlight
Protection Features	Short-circuit protection over-temperature protection
Dimensions	45mm x 26mm x 15mm (without heat sink)
Weight	Approximately 40g
Operating Temperature	-20°C to 85°C (storage: -40°C to 105°C)
