Description: 1. The PCI Port Cord Motherboard IC Analyzer is an advanced diagnostic tool designed specifically for analyzing Integrated Circuit (IC) chips on PCI (Peripheral Component Interconnect) cords connected to motherboards. 2. This device offers high-speed data transfer rates, enabling it to capture and decode complex signaling patterns in real-time. It supports various communication protocols commonly used in IoT components, such as USB, Ethernet, PCIe, and others. 3. One of its primary features is the ability to identify and diagnose issues with IC chips, including faulty connections or malfunctioning components, which can save time and resources by eliminating the need for extensive troubleshooting or replacement of entire motherboards. 4. The PCI Port Cord Motherboard IC Analyzer comes with an intuitive user interface, making it accessible to both technical professionals and informed hobbyists. It provides clear visual representations of the data being captured and offers detailed re
| Specification | Details |
|---|---|
| Product Description | A tool used to analyze and troubleshoot motherboard ICs connected via PCI ports |
| Interface Type | 50-pin IDC connector compatible with most PCI motherboards |
| Operating Temperature | 0°C to 60°C (operating) -20°C to 80°C (storage) |
| Power Consumption | 5V DC 200mA max power consumption |
| Measurement Range | Measures voltage frequency and timing signals on PCI ports |
| Accuracy | ±1% for voltage measurement ±100ps for timing signal measurement |
| Sampling Rate | Up to 500 MHz sampling rate for accurate signal capture |
| Display Options | 2-line LCD display showing measurement results with options for beep or LED indicators |
| Connectivity Options | USB cable connection for PC communication and data transfer |
| Software Compatibility | Compatible with Windows operating systems (drivers available) |
| Dimensions | Compact design with dimensions TBD (subject to product prototype) |
| Weight | TBD (subject to product prototype) |
