Original WCS2720 Hall Effect based Linear Current Sensor (0-20A)

This product is not available in your location yet

Description: 1. Original WCS2720 is a Hall Effect based linear current sensor designed for measuring currents between 0-20 Amperes (A). 2. Features: It comes with a compact size (LxWxH: 53.4mm x 17mm x 6.7mm), low power consumption (≤5mW), and an output voltage range of ±5V to suit various applications. 3. Accuracy and Linearity: This sensor offers high accuracy (+2% FS) and linearity with a temperature coefficient as low as ±0.01%/°C, ensuring reliable current measurement. 4. Easy-to-Use Interface: The sensor features an analog voltage output (0.25V/A), making it straightforward to interface with external devices and data acquisition systems. 5. Robustness and Protection: WCS2720 is designed to operate in harsh environments, including high temperatures (-40°C to +85°C) and overvoltage (up to 36V), ensuring reliable performance under various conditions. 6. Low Noise and Low Sensitivity: The sensor has low noise (≤1mVrms) and low sensitivity to magnetic fields, which helps maintain precise cur

View Technical Documentation

Specification	Details
Operating Range	0-20 A
Sensitivity	100 mV/A
Operating Voltage	4.5 V to 30 V
Supply Current	3 mA (max)
Output Type	Analog (proportional to current)
Output Signal	Linear voltage output (Vout = Isens \\ Iin)
Current Sensing Range	0-20 A adjustable via Vref
Operating Temperature	-40°C to +85°C
Storage Temperature	-55°C to +125°C
Humidity	20% to 80% non-condensing
