Description: 1. The HT12A Encoder is a microcontroller-based quadrature encoder module designed for position sensing applications in IoT projects and automation systems. 2. Features: It comes with two optically isolated input channels (A and B) for detecting the transitions of rotating shafts or discs, producing 16 different digital output codes. 3. Quadrature Encoding: The module uses quadrature encoding, which allows determining both direction and rotation speed by observing the transition pattern between inputs A and B. 4. Versatile Output: The HT12A Encoder supports four different signal configurations: Type A, Type B, Type C, and Type F, providing flexibility to accommodate various project requirements. 5. Operating Voltage: This encoder module operates within a wide voltage range of 3V to 14V DC, making it suitable for diverse IoT projects. 6. Easily Interface: The HT12A Encoder is simple to interface with microcontrollers and single-board computers like Arduino, Raspberry Pi, etc., usi
| Specification | Details |
|---|---|
| Supply Voltage | 4.5V to 6V (single supply) |
| Power Consumption | Typically 10 mA at 5V |
| Encoder Data Rate | Up to 1 Mbps |
| Keying Mode | Active-High Active-Low or Latched |
| Decoding Address | 12-bit binary code |
| Pulse Width | Adjustable (programmable) |
| Operating Temperature | -40°C to +85°C |
| Package Type | DIP-14 |
| Dimensions | 0.3" x 0.7" (DIP-14) |
| Weight | Approximately 1 gram |
