Description: 1. The Original WCS2702 is a Hall Effect-based linear current sensor designed for measuring currents up to 2.0 Amperes with high accuracy. 2. Features: It offers a wide operating temperature range from -40°C to +85°C, making it suitable for various applications. The sensor comes with an adjustable gain of up to 16x, allowing users to customize the output signal level. 3. Linearity: With a linear output, the WCS2702 provides excellent accuracy and repeatability, making it ideal for precise current measurement requirements. 4. Integration: The sensor can be easily integrated into control systems through its analog voltage output. No external excitation is required, simplifying implementation and reducing overall system complexity. 5. High Resolution: With a 12-bit ADC resolution, the WCS2702 offers high measurement precision for applications where accurate current monitoring is essential. 6. Protection: The sensor's built-in overcurrent protection function ensures safe operation by
| Specification | Details |
|---|---|
| Operating Voltage | 3.5V to 36V |
| Measurement Range | 0 A to 2000 mA |
| Accuracy | ±1% (typical) ±2% (maximum) |
| Linearity Error | ±0.8% (typical) ±1.5% (maximum) |
| Temperature Coefficient | -10 ppm/°C |
| Operating Temperature | -40°C to 85°C |
| Output Type | Analog Output (Vout = Vcc \\ Iin / Iref) |
| Sensitivity | 0.02 A/V |
| Current Reference | Internal Current Reference |
| Package Type | SOT-23 |
| Mounting Orientation | Surface Mount |
| Weight | ~0.6 grams |
