Description: 1. Microwave Radar Human Body Sensor is a non-contact, continuous monitoring system that utilizes microwave radar technology to detect the presence and movement of humans in real-time. 2. Features: It operates on the 24GHz frequency band, ensuring minimal interference with other wireless devices. The sensor has an adjustable detection zone and can cover areas up to 10 meters wide. 3. Safety: This sensor is safe for use around humans as it does not emit radiation like some other types of sensors. It also doesn't require physical contact with the body, ensuring hygienic operation. 4. Versatility: Suitable for various applications including security systems, smart homes, healthcare monitoring, and industrial automation. Can be integrated with IoT platforms for remote monitoring and control. 5. Real-time Detection: The sensor provides instantaneous human detection, allowing for immediate response to intrusions or other events. This makes it ideal for applications where quick action is
| Specification | Details |
|---|---|
| Frequency | 24 GHz ISM band |
| Detection Range | Up to 10 meters (33 feet) |
| Sensitivity | -20 dBm (typical) |
| Field of View | ±30° horizontal ±15° vertical |
| Resolution | 1° x 1° (typical) |
| Accuracy | ±2 cm (7.9 in) |
| Response Time | < 100 ms |
| Power Consumption | ≤ 5 mA @ 3.3 V |
| Operating Voltage | 3.3 V to 5.5 V |
| Temperature Range | -20°C to 60°C (operating) |
| Humidity Range | 0% to 95% (non-condensing) |
| Dimension | 50 mm x 25 mm x 10 mm |
| Weight | 15 grams |
