Description: 1. Size and Dimension: The SK8 8mm Linear Rail Shaft is an essential component of linear motion systems, with a standard size of 8mm in diameter and varying lengths to suit different applications. 2. Material: It is typically made of high-strength steel or stainless steel for superior rigidity, durability, and load capacity. This makes it suitable for heavy-duty use in industrial automation, CNC machines, and other precision engineering applications. 3. Linear Motion: The primary function of this shaft is to provide a smooth, guided linear motion by sliding within the rail grooves, ensuring precise positioning and accurate repeatability. 4. Load Capacity: Depending on the material and length, the SK8 8mm Linear Rail Shaft can support varying loads. It's crucial to consider the weight of attached components and the required precision while selecting an appropriate shaft for your application. 5. Low Friction and Wear: The shaft features a polished or hard-anodized surface, reducing
| Specification | Details |
|---|---|
| Shaft Diameter | 8mm (0.315 inches) |
| Material | High-quality steel (HSS or similar) |
| Linear Bearing Type | Ball bearing |
| Rail Width | 16mm (0.63 inches) |
| Rail Thickness | 1.5mm (0.06 inches) |
| Shaft Length | Variable (customizable upon request) |
| Precision Grade | High precision (up to ±0.005mm) |
| Load Capacity | Up to 10kg (22lbs) per meter |
| Operating Speed | Up to 1m/s (3.6ft/s) |
| Environmental | Suitable for indoor and outdoor use |
