Description: 1. The 12V Relay Cube is a compact, versatile, and easy-to-use IoT component designed to operate electrical appliances or systems via remote control or automated processes. 2. Key feature includes a single-pole double-throw (SPDT) relay with a form factor of only 36mm x 36mm x 18mm, making it perfect for space-constrained projects. 3. It operates on a 12V DC power supply and can handle up to 30A of current per contact, enabling control over higher-power loads like lamps, pumps, or motors. 4. The Relay Cube comes with three configurable input modes: normally open (NO), normally closed (NC), and changeover (CO), offering greater flexibility in various applications. 5. Each input can be connected via screw terminals, and the relay's status can be monitored through an integrated LED indicator for easy troubleshooting and real-time feedback. 6. The component is designed for ease of integration with different control systems like microcontrollers, sensors, or software applications thro
| Specification | Details |
|---|---|
| Power Input | 12V DC 10A (max) |
| Relay Type | SPDT (Single Pole Double Throw) |
| Switching Capacity | 250V AC/30A or 125V DC/50A |
| Current Rating | 5A (max) per pole |
| Voltage Rating | 12V DC across all poles |
| Contact Material | Gold-plated brass |
| Operate Time | ≤ 1 ms |
| Release Time | ≤ 4 ms |
| Max Switching Cycle | 10^6 cycles |
| Operating Temperature | -20°C to +80°C (max) |
| Storage Temperature | -40°C to +85°C (max) |
| Humidity | Up to 95% RH (non-condensing) |
| Dimensions | 5.7cm x 4.2cm x 1.8cm |
