Description: 1. LM2596 Mini 360 is a compact step-down DC-DC converter module, based on the LM2596 buck converter chipset. It offers adjustable output voltage from 1.5V to 36V and a maximum continuous output current of up to 3A. 2. Versatile Applications: This module is widely used in various IoT projects, aircraft models, drones, robots, electronic toys, and any other devices requiring a regulated power supply. Its small size makes it ideal for portable applications where space is limited. 3. Efficiency and Low Heat: The LM2596 Mini 360 module boasts an efficiency of up to 88%, reducing the heat generation and ensuring stable output voltage even under heavy loads. This feature is particularly beneficial in aerospace applications where maintaining stable power supply is crucial. 4. Adjustable Output Voltage: Users can easily set the desired output voltage by turning the adjustment potentiometer, making it perfect for devices with varying power requirements or sensitive components that need spec
| Specification | Details |
|---|---|
| Input Voltage Range | 3V to 36V |
| Output Voltage Range | Adjustable 1.2V to 37V (adjustable via potentiometer) |
| Output Current Limit | 3A (depending on the input voltage and efficiency) |
| Efficiency | Up to 95% |
| Switching Frequency | Fixed at 625kHz |
| Protection Features | Over-temperature protection short-circuit protection over-current protection |
| Package Type | Miniature step-down module in a small plastic case (about 1.5" x 0.8") |
| Operating Temperature | -40°C to 85°C |
| Dimensions | Approximately 35mm x 22mm x 14mm |
