Arduino MEGA 2560 Atmel R3 compatible Board

This product is not available in your location yet

Description: 1. The Arduino Mega 2560 is a microcontroller board based on the Atmel AVR microcontroller. It is an upgraded version of the popular Arduino Mega 256 R2, compatible with the R3 shields. 2. This board features 54 digital input/output pins (of which 15 can be used as PWM outputs), 16 analog inputs, 4 serial ports, a 16x2 character LCD interface, and a USB connection for programming and communication. 3. The Arduino Mega 2560 has an Atmel microcontroller with 256 KB Flash memory for storing code, 8 KB SRAM for volatile data, and 16 KB EEPROM for non-volatile data storage. 4. Its extensive connectivity options include SPI, I2C, UART, TWI, and various other interfaces like SDA, SCL, RxD, Tx, MOSI, MISO, SS, etc. This board is particularly suitable for projects requiring multiple peripherals or expansion boards. 5. The Arduino Mega 2560 can be powered using the DC jack, a USB connection, or an external power source. It operates on an internal 16 MHz clock and accepts input voltages from

View Technical Documentation

Specification	Details
Processor	ATmega2560-16AU (8-bit AVR)
Clock Speed	16 MHz
Flash Memory	256 KB (2 x 128 KB banks)
SRAM	8 KB
EEPROM	4 KB
Digital I/O Pins	54 (14 with PWM 12 with Analog Read)
Analog Inputs	16
Analog Outputs	6
Communication	USB UART SPI I2C ICSP
Operating Voltage	7-12.6 V (regulated to 5V)
Power Consumption	Typical: 50 mA Max: 250 mA
Dimensions	101.52 mm x 53.41 mm
