Description: Owon SDS 1022: 20 MHz Digital Storage Oscilloscope 1. High Resolution: Features a high resolution XGA (1024 x 768) TFT color LCD display, ensuring clear visualization of complex waveforms. 2. Deep Memory Depth: Offers deep memory capacity up to 32 Mpts, allowing for long data capture and analysis of detailed events. 3. Versatile Triggering: Supports various trigger sources including normal, automatic, software, and external triggers. 4. Wide Bandwidth: Operates at a wide bandwidth of 20 MHz with an input impedance of 1 MOhm and 50 Ohms, suitable for analyzing high-frequency signals. 5. Data Transfer: Provides various interfaces like USB, LAN, and IEEE-488 GPIB for data transfer and real-time analysis using external software. 6. Built-in Functions: Equipped with essential built-in functions such as FFT, Math, Statistic, and Marker for advanced signal analysis. 7. Connectivity: Compatible with various probes and extension modules for extended functionality and versatility in applicatio
| Specification | Details |
|---|---|
| Bandwidth | 20 MHz |
| Sample Rate | Up to 1 GSa/s (single-channel) |
| Vertical Resolution | 8-bit up to 4.5 digits |
| Memory Depth | 28 Mpts (max) 2 kpts (min) |
| Display Mode | Waveform Bar Chart FFT etc. |
| Trigger Modes | Single Auto Glitch Runt Pulse |
| Trigger Level | Software-controlled |
| Input Impedance | 1 MΩ (50 Ω or 1 MΩ) |
| Voltage Range | ±10 V/div -40 dBm to +20 dBm |
| Timebase Range | 200 ps/div to 2 s/div |
| Probe Support | Supports Owon high-impedance probes |
| USB Host Port | Yes USB 2.0 |
| Power Supply | External power supply (9 V DC) |
