Fermion MEMS Gas Detection Sensor Hydrogen Sulfide (H2S)

Stufin

Fermion MEMS Gas Detection Sensor Hydrogen Sulfide (H2S)

This product is not available in your location yet

Description: 1. Sensor Type: The Fermion MEMS Gas Detection Sensor is a Micro-Electro-Mechanical Systems (MEMS) hydrogen sulfide (H2S) gas sensor, utilizing a microfabricated transducer to convert the physical properties of hydrogen sulfide gas into an electrical signal. 2. High Selectivity: The sensor exhibits excellent selectivity towards H2S gas with a detection limit as low as 10 parts per million (ppm), making it suitable for applications where precise H2S monitoring is crucial, such as oil and gas production, wastewater treatment, and industrial processes. 3. Low Power Consumption: The MEMS sensor consumes minimal power, typically under 10 mW, which is essential for battery-powered IoT systems and long-term deployment in remote locations. 4. Compact Design: With a small form factor, the sensor can be easily integrated into various IoT systems and platforms, including gas monitoring stations, environmental control systems, or portable gas detection devices, allowing for flexible and versat

View Technical Documentation

Specification	Details
Sensor Type	Microelectromechanical Systems (MEMS)
Detection Gas	Hydrogen Sulfide (H2S)
Detection Range	Typically: 0 - 100 ppm Max: 200 ppm
Accuracy	±5% of reading at 25°C and 1 atm
Response Time	< 30 seconds
Stability	≥ 10 days in a controlled environment
Operating Temperature	-20 to 50°C
Storage Temperature	-40 to 60°C
Humidity Range	0-80% relative humidity
Power Supply	3.3V typically via I2C bus
Interface	I2C (Inter-Integrated Circuit)
Digital Output	PWM (Pulse Width Modulation)
Analog Output	Optional 0-5V
Dimension	Typically 26mm x 22mm x 10mm
Weight	Approximately 20 grams
