Description: 1. CP2102 is a USB-to-UART bridge chip designed as a converter, enabling the connection of microcontrollers or other devices to a PC through a standard USB interface. 2. Features: It supports baud rates up to 3 Mbps and automatic flow control (XON/XOFF), making it suitable for various data transfer applications. The chip also has built-in ESD protection, ensuring the device's longevity. 3. Efficient Communication: CP2102 offers efficient communication between a microcontroller and a PC by acting as an intermediary, eliminating the need for additional hardware for serial communication. 4. Versatile Application: It can be used in various projects such as robotics, automation, data acquisition systems, and other IoT projects that require bidirectional communication between devices and a PC. 5. Easy to Use: The CP2102 comes with pre-compiled drivers for popular operating systems like Windows, Linux, and MacOS, simplifying the setup process for users. 6. Integration with Microcontroll
| Specification | Details |
|---|---|
| Interface | USB (Host) |
| Operating System | Windows macOS Linux |
| UART Interface | 3.3V TTL up to 3 Mbps |
| GPIO Pins | 12 GPIO pins |
| Power Requirements | 5V DC up to 500 mA |
| Operating Voltage | 5V with power regulation |
| Temperature Range | -40°C to +85°C |
| Dimensions | 33 mm x 14.5 mm x 7.5 mm |
| Weight | approximately 20 grams |
| Communication Speed | up to 3 Mbps (UART) |
| Data Transfer Size | up to 16 MB |
| Certifications | FCC ID: PN-12345 CE marked |
