Description: 1. The Arduino UNO Sensor Shield V5 is an expansion board designed to simplify the process of connecting various sensors to the Arduino UNO microcontroller. 2. It features a modular design with separate areas for common I2C and analog sensors, allowing users to easily connect multiple sensor types without overcrowding the Arduino board. 3. The shield includes level shifters for I2C sensors, enabling seamless communication between sensors that operate at different voltage levels than the Arduino UNO. 4. A total of 15 input pins are available on the shield for various sensor connections, including analog, digital, and I2C inputs. 5. The shield also includes a power regulator, ensuring stable power supply to connected sensors and reducing voltage drops that can affect sensor readings. 6. Unique benefits include easy sensor prototyping, reduced wiring complexity, and the ability to stack multiple shields for added functionality. 7. Compatible with popular sensors like temperature, h
| Specification | Details |
|---|---|
| Board Type | Arduino Uno-compatible sensor shield |
| Compatibility | Arduino Uno Mega (with modifications) |
| Sensor Connectors | 15-pin header for easy module attachment |
| Analog Inputs | 6x analog input pins with jumper wires |
| Digital Inputs/Outputs | 8x digital input/output pins (SCL SDA INT0 INT1 TX RX) |
| Power Supply | 5V DC power supply regulated by the shield |
| Voltage Range | 3.3V to 5V DC voltage range |
| Temperature Sensor | Integrated temperature sensor (DS18B20) |
| Accelerometer | Integrated accelerometer (MPU6050) |
| Gyroscope | Integrated gyroscope (MPU6050) |
| Humidity Sensor | Integrated humidity sensor (DHT11) |
| SD Card Slot | Micro-SD card slot for data logging |
| Operating System | Compatible with Arduino IDE (Windows Mac Linux) |
| Dimensions | 8.5cm x 7.5cm x 2cm (3.35in x 2.95in x 0.79in) |
