Description: 1. The XL6019 is a versatile DC-DC boost power supply module capable of delivering up to 5 Amperes of adjustable output voltage, ranging from 3V to 24V. 2. Featuring an adjustable input voltage range between 7V and 28V, this module can be used in various IoT projects where a stable power supply is essential. 3. Unique benefits include over-voltage protection (OVP) and reverse polarity protection for improved safety and reliability during operation. 4. The XL6019 also features adjustable output current limiting, allowing users to set maximum current levels to prevent potential damage to connected components or loads. 5. This boost converter module uses a constant frequency switching design to ensure efficient power conversion and reduced heat dissipation. 6. With a compact size (L: 30mm x W: 22mm), the XL6019 is suitable for space-constrained IoT applications or projects requiring portable power supplies. 7. The module's pin header design allows for easy integration and customiza
| Specification | Details |
|---|---|
| Input Voltage | 3V - 32V (3.2V to 32V) |
| Output Current | Up to 5A ( adjustable via potentiometer) |
| Adjustable Range | 1.25V to 37V |
| Efficiency | Up to 96% |
| Switching Frequency | Fixed at 380KHz |
| Dimension | 30x20mm (module size) |
| Material | High-quality PCBA and metal case |
| Operating Temperature | -40°C to 85°C |
| Protection Features | Short-circuit protection over-current protection thermal protection |
| Mounting Type | PCB mounting (easy to integrate with any project) |
