Description: 1. L293D Motor Driver Board Overview: The L293D is a six-channel, single-power bi-directional DC motor driver. It's widely used for controlling two DC motors or one bidirectional motor with forward and reverse functions. 2. Features: This motor driver board includes six independent channels to control individual motors, each with an enable pin (IN1-IN6), two input pins for direction (IN7-IN8), a common ground terminal, and three power terminals: VCC, GND, and IN. 3. Easy Control: The L293D motor driver board simplifies motor control as it can be operated with just 4 control pins (two for each motor channel) from a microcontroller or any digital logic device. 4. Versatile Applications: It is suitable for various applications such as robotics, CNC machines, RC cars, and home automation projects due to its ability to handle multiple motors independently. 5. Protection Circuitry: This driver features protection circuits including over-voltage, under-voltage, short circuit, and thermal
| Specification | Details |
|---|---|
| Chip Type | L293D IC 16-pin Dual H-Bridge |
| Supply Voltage | 4.5V to 36V DC (±15%) |
| Output Current | Up to 600mA per channel (peak) |
| Voltage Drop | 0.3V (typical) |
| Package Type | DIP-16 (Dual Inline Package) |
| Operating Temp | -40°C to +85°C (ambient temperature) |
| Logic Level | TTL (5V logic level) |
| Channel Count | 2 H-Bridge channels (4 inputs) |
