Description: 1. The Arduino IRF520 MOSFET Driver Module is an interface board designed to drive high current or high power MOSFETs using Arduino boards. It features a single-channel, opto-isolated design for safe and efficient power control. 2. Compatibility: This module is compatible with all standard Arduino boards that have a minimum of six digital pins. It is also suitable for various microcontroller projects requiring MOSFET switching. 3. Features: Opto-isolated design ensures protection against voltage spikes and current surges between the control circuit and the load. The IRF520 N-channel MOSFET can handle continuous currents up to 16.7A and peak currents up to 30A. 4. MOSFET Protection: The module includes protection diodes across the MOSFET to prevent reverse voltage damage, while a flyback diode prevents inductive load spikes when the MOSFET is turned off. 5. Ease of Use: This driver module simplifies MOSFET control for Arduino users by handling high-current switching tasks and elimi
| Specification | Details |
|---|---|
| Module Type | Arduino-compatible MOSFET driver |
| MOSFET Used | IRF520 N-Channel Power Enhancement |
| Operating Voltage | 3.3V to 5V (with built-in voltage regulator) |
| Operating Current | up to 1A |
| Power Switching | High-side switching MOSFET driver |
| Gate Drive | PWM capable with internal R-C filter |
| Input Protection | Overvoltage protection (up to 6V) |
| Thermal Protection | Thermal shutdown (at around 150°C) |
| Dimensions | Typically around 1.5 cm x 0.8 cm |
